Another new exciting technology developed by HY-SAVE® introduces the HY-EJECTOR™ Eductor LPA® liquid refrigerant pump designed to provide unprecedented performance combined with an Eductor to replace the system’s inefficient vapour compressors is capable of providing supersonic flow rates and delivery pressures of up to 500 psi (35 bar) above inlet pressures. High efficiency ECM motors can be supplied as standard and are external to the pressure chamber. About the LPA® Pump
“Tomorrows Refrigeration Technology Today”
Could “Minimising the Head Pressure” be costing you more than you think?
Minimising the condensing temperature in attempt to save energy can have a negative effect on system running cost if not taking into account certain thermodynamic changes. As condensing pressure is reduced, the effect of flash gas in the liquid line rises sharply. 2% flash gas by weight in the liquid line at 38°C (F) condensing temperature will occupy 28% of the liquid line with vapour at 21°C (70F) condensing temperature. Flash gas produces no refrigeration effect, electronic expansion valves would simply open up wider in attempt to deliver cooler temperatures and allow this flash gas to pass through to the cooling coils. As a result, the compressors will require additional staging or cylinders to re-compressor this gas which has already been compressed once before. In summary, you could be wasting more than you think. View our minimising the head pressure slide show here.
Energy Efficient Refrigeration LPA® Pumps..
for Supermarkets, Process Cooling, Cold / Frozen Storage, Blast Freezing, Data Centres and much more!
HY-SAVE® manufactures a range of energy efficient refrigeration LPA® pumps that saves energy in refrigeration or air conditioning applications. Depending on your geographical location, energy savings can be in the region of 12 to 48% annually. Recently launched, our new range of high energy efficient Co2 LPA® pumps designed specifically for Co2 refrigeration applications to further improve efficiencies.
At each end of these sliding banners are arrows. Click through to see our other features…
Our new range of Co2 pumps have been designed to meet the requirements of natural refrigerants in refrigeration or air conditioning systems to help save our environment. Our equipment eliminates 600,925 metric tons of CO2 emissions every year, and as more businesses discover HY-SAVE, the benefits to our planet increase globally.
Previously our manufactured sub-assemblies had to be transported a distance of 290 miles return per day by road which has been reduced to 11 miles return per day.
Environmental Carbon Reduction Credits 33,145 kg or 73,052 lb/year
as a carbon reduction initiative to reduce the number of international passageways. We have increased our bulk volume to deliver more product less frequently.
Environmental Carbon Reduction Credits 28,900 kg or 63,695 lb/year
in close proximity to our OEM factories and production lines to eliminate daily transportation costs harmful to the environment. Bulk consignments are delivered less frequently and locally.
Environmental Carbon Reduction Credits 82,125 kg or 37,216 lb/year
In “Liquid Pressure Amplification” How is my power being wasted?
Present day designs with head pressure controls were developed some 65 years ago. Higher head pressures were designed into a refrigeration system so it would function well at lower outdoor temperatures. These higher pressures were needed to prevent flash gas and deliver the refrigerant to the refrigeration cooling coils. Power costs a half a century ago were not a factor so the added cost of operation with lower efficiency did not matter. At today’s power costs, inefficiency is an unacceptable part of ones refrigeration overhead. See Brochure: Improving-Refrigeration-Dynamics-LPA
|Energy Saving Cooling|
|Recent energy saving systems requiring LPA® pumps include:|
|Energy Saving HY-DRY Ultimate De-Humidification|
|Energy Saving LDS™Liquid Delivery Systems|
|Co2 / Propane Ground Source Heat Pump applications|
|Propane Free-Cooling chiller applications|
|HFC Direct Expansion Free-Cooling applications|
|Co2 Sub-Critical low temperature applications|
|Co2 Re-circulation Systems|
|Two phase heat transfer systems|
Improved Cooling & Dehumidification for Supermarkets, Commercial & Industrial Applications by as much as 70%
HY-DRY™ Technology provides an affordable moisture removal increase by as much as 70% relative to existing systems without HY-DRY™. This lower humidity allows your building to change from “cold and clammy” to cool and dry fresh air. Everyone in the building will enjoy the ultimate comfort. A Cure for “Sick Building Syndrome” The most important factor in reducing airborne mold and bacteria count is the control of moisture in the building. At the end of these sliding banners are arrows, click through to see our other features.
Simplicity, versatility and reliability have been the hallmark of the LPA® brand of pumps for over 25 years. Versatility is emphasised by the wide range of uses. Simplicity is highlighted by the ” orbital” magnetic drive, leak proof design. Reliability is proven by a combined operating record of over 315 million LPA pump hours in a full time refrigeration environment.
Our latest range of self unloading CO2 LPA pumps inherit the exceptional reliability of the LPA pump range and covers a wide range of operating conditions from 1 to 65 GPM (3.78 to 245 litres/min), design working pressures of 1087 psi (75 bar) as standard and capable of providing up to 83 feet (25 metres) of head to suit most industrial applications.
At the end of these sliding banners are arrows, click through to see our other features>>
for Co2 and Propane applications…
HY-SAVE® has been manufacturing a high quality range of LPA® (Liquid Pressure Amplification) maintenance-free pumps for over 25 years.
Since 2007, the product line has been extended to include high pressure models able to reduce Co2 flash gas and improve the overall performance of CO2 refrigeration systems and greater energy savings for natural refrigerants.
Our latest range of self unloading CO2 and HFC LPA® pumps inherit the exceptional reliability of the LPA® range and covers a wide range of operating conditions from 1 to 75 GPM (3.78 to 280 litres/min), design working pressures of 1087 psi (75 bar) as standard and capable of providing up to 85 feet (25 metres) of head to suit most industrial applications.
Recently launched Model 925 available with either copper or stainless steel connection stubs to suit a wide range of applications.
Helping to reduce global warming… The Reliable, Cool Solution..
At the heart of the HY-SAVE solution is the LPA® pump. Unlike conventional pumps, it has minimal moving parts and is extremely reliable. HY-SAVE LPA pumps have been known to perform faultlessly for 20 years –so you can look forward to savings year after year, with ROI again and again.
Our Brochure>> HY-SAVE-Making-Refrigeration-More-Efficient-Web
Either ends of these sliding banners are arrows, click through to see some of our features.
Refrigeration Energy savings for Supermarkets and Cold Storage applications
HY-SAVE® supplies major supermarkets worldwide with their patented refrigeration energy saving Liquid Delivery Systems LDS™ for new stores and simplified retrofit applications. Standard and custom sizes are available through HY-SAVE’s representatives. Refrigeration energy savings are in the region of 20 to 45% annually. Available in a range of sizes from 50 to 1,400 kW (15 to 400 tons) of cooling duty.
Recently launched, cost effective web based module to measure refrigeration energy usage, pressures, temperatures, and alarm any abnormalities such as high condensing temperatures or other losses or inefficiencies.
A variable factored baseline is provided to measure prior system efficiency, characteristics and operating performance. Data is averaged and transferred every 15 minutes to a dedicated server of choice for reporting or raw data retrieval.
At the end of these sliding banners are arrows, click through to see our other features >>>
With tens of thousands of LPA® pumps in the field running flawlessly for over 20 years, HY-SAVE® is proud to offer an extended 7 year extensive warranty on any parts. Extended warranty is offered with any new LPA pumps purchased on and after August 2011.
Each average size LPA® pump saves 40,000 to 80,000 kwh per year in a commercial environment. HYSAVE® LPA® Technology assures you that your return on investments (ROI) is guaranteed to meet your reduction in energy initiatives. Contact us to register your LPA® pumps today.
The wholesale price of electric is closely linked to the price of oil, which itself hit a record high of just under $140 a barrel in June. Around the world, South Africa reports an energy increase of 25%, northern European countries, 14% and in the UK, businesses are being urged to prepare for energy price hikes by an estimated average of 12% for business electricity tariffs over the next six months.
At the end of these sliding banners are arrows, click through to see our other features>>
Quality is our commitment and satisfaction, our requirement;
Every product or service has a requirement: a description of what the customer needs. When a particular product meets that requirement, it has achieved quality.
HY-SAVE® has met that requirement and has been manufacturing LPA® pumps for over 25 years. Over the past 2 years the company has proudly maintained zero defects in its manufacturing control process. This has been achieved after the introduction of many new approaches to existing quality control techniques and total quality management (TQM), a more specific approach to quality assurance (QA). Click through to view our other features>>
At the holiday season, our thoughts turn gratefully to those who have made 2012 such an environmentally friendly year for us once again. THANK YOU.. from all of us at LPA® Technologies! We look forward to working with you again in 2013 and beyond….
at the end of these sliding banners are arrows, click through to see our refrigeration energy savings >>
